Muffle Furnace 3 Lt, 1000°C
Muffle Furnace 3 Litter , 1000°C , 220-240 V 50-60 Hz
EKE 1450:
The Muffle Furnace are widely for determining various properties of construction materials, and they cover a temperature range 1000°C and front loading for easy operation and of a double skin construction to maintain a cool outer case.
Excellent temperature control is provided by a PID digital control system. A vertical counter balanced door keeps the hot insulation away from the operator which opens in an upwards movement. The Furnace has a safety switch which isolates the power the door is opened.
Technical Specifications :
• Temperature Controller : HONEYWELL DC1010
• Max. Temperature : 1000°C
• Max. Continuous Temperature : 950°C
• Temp. Deviation at Set Point : ± 2°C
• Heat Up Time to Max. Temp. : 50 min
• Internal Volume : 2.7 L
• Phase : 1
• Internal Dimensions : 100 x 135 x 200 mm
• External Dimensions : 425 x 320 x 360 mm
• Weight (Approx.) : 20 kg
• Power : 2000 W
Muffle Furnace 6 Lt, 1100°C
Muffle Furnace 6 Litter , 1100°C , 220-240 V 50-60 Hz
EKE 1455:
The Muffle Furnace are widely for determining various properties of construction materials, and they cover a temperature range 1100°C and front loading for easy operation and of a double skin construction to maintain a cool outer case.
Excellent temperature control is provided by a PID digital control system. A vertical counter balanced door keeps the hot insulation away from the operator which opens in an upwards movement. The Furnace has a safety switch which isolates the power the door is opened.
Technical Specifications :
• Temperature Controller : HONEYWELL DC1010
• Max. Temperature : 1000°C
• Max. Continuous Temperature : 1050°C
• Temp. Deviation at Set Point : ± 2°C
• Heat Up Time to Max. Temp. : 65 min
• Internal Volume : 6.3 L
• Phase : 1
• Internal Dimensions : 150 x 210 x 200 mm
• External Dimensions : 650 x 550 x 580 mm
• Weight (Approx.) : 56 kg
• Power : 1500 W
Muffle Furnace 5lt, 1200°C
Muffle Furnace 5 Litter , 1200°C , 220-240 V 50-60 Hz
EKE 1460:
The Muffle Furnace are widely for determining various properties of construction materials, and they cover a temperature range 1200°C and front loading for easy operation and of a double skin construction to maintain a cool outer case.
Excellent temperature control is provided by a PID digital control system. A vertical counter balanced door keeps the hot insulation away from the operator which opens in an upwards movement. The Furnace has a safety switch which isolates the power the door is opened.
Technical Specifications :
• Temperature Controller : HONEYWELL DC1010
• Max. Temperature : 1200°C
• Max. Continuous Temperature : 1150°C
• Temp. Deviation at Set Point : ± 2°C
• Heat Up Time to Max. Temp. : 50 min
• Internal Volume : 5 L
• Phase : 1
• Internal Dimensions : 140 x 180 x 200 mm
• External Dimensions : 650 x 550 x 580 mm
• Weight (Approx.) : 56 kg
• Power : 2000 W
Muffle Furnace 5lt, 1600°C
Muffle Furnace 5 Litter , 1600°C , 380 V 50 Hz
EKE 1465:
The Muffle Furnace are widely for determining various properties of construction materials, and they cover a temperature range 1600°C and front loading for easy operation and of a double skin construction to maintain a cool outer case.
Excellent temperature control is provided by a PID digital control system. A vertical counter balanced door keeps the hot insulation away from the operator which opens in an upwards movement. The Furnace has a safety switch which isolates the power the door is opened.
Technical Specifications :
• Temperature Controller : HONEYWELL DC1010
• Max. Temperature : 1600°C
• Max. Continuous Temperature : 1550°C
• Temp. Deviation at Set Point : ± 2°C
• Heat Up Time to Max. Temp. : 75 min
• Internal Volume : 5 L
• Phase : 1
• Internal Dimensions : 140 x 150 x 240 mm
• External Dimensions : 650 x 550 x 580 mm
• Weight (Approx.) : 65 kg
• Power : 4900 W
