Cannon–Manning /Fenske Viscometer
Cannon – Manning /Fenske Viscometer
Ref. Standard IS: 1206 (II) & IS IS:1206 (III)
EKE 532:
Cannon – Manning Viscometers are designed for the determination of the absolute viscosity of bitumen & Cut – backs by a vacuum capillary method at specified temperatures. Cannons Fenske Viscometers are designed for the determination of the Kinematic viscosity by a vacuum capillary method.
Various types of Glass capillary viscometer are used to measure the viscosities because no single capillary Viscometer is ideally suited for all viscosity determinations.
Suitable for operation on 220 V, 50 Hz, single Phase AC Supply
Features
• Used for the measurement of absolute viscosity of highly materials
• Viscometers of sizes 12 & 13
• Applicable to materials of viscosities in the range of 360 to 8000 poise
Cannon – Manning Fenske Viscometer Compressing the following:
- Cannon – Manning Capillary tubes of sizes 12 13
- Cannons ,Fenske Capillary tubes of sizes 6 & 7
- Kinematic Viscometer Bath with a provision for 6 tests
- Vacuum System
- Thermometer of IP-5C of a range from 2 to 300°C as per specification
- Thermometer of IP-64C of a range from – 20 to 102°C (0.2° resolution)
Optional Accessories:
EKE 53203: Cannon – Manning Capillary tubes of size of 12
EKE 53204: Cannon – Manning Capillary tubes of size of 13
EKE 53211: Cannon – Fenske Capillary tubes of size of 6
EKE 53212: Cannon – Fenske Capillary tubes of size of 7
EKE 53213: Thermometer of IP-5C of a range from 2 to 300°C as per specification
EKE 53214: Thermometer of IP-64C of a range from – 20 to 102°C (0.2° resolution)
Cannon – Manning /Fenske Viscometer(EKE 532-1)
Cannon – Manning /Fenske Viscometer -
Ref. Standard IS: 1206 (II) & IS IS:1206 (III)
EKE 532-1:
Cannon – Manning Viscometers are designed for the determination of the absolute viscosity of bitumen & Cut – backs by a vacuum capillary method at specified temperatures. Cannons Fenske Viscometers are designed for the determination of the Kinematic viscosity by a vacuum capillary method.
Various types of Glass capillary viscometer are used to measure the viscosities because no single capillary Viscometer is ideally suited for all viscosity determinations.
Suitable for operation on 220 V, 50 Hz, single Phase AC Supply
Features:
• Used for the measurement of absolute viscosity of highly materials
• Viscometers of sizes 12 & 13
• Applicable to materials of viscosities in the range of 360 to 8000 poise
Cannon – Manning Fenske Viscometer Compressing the following:
- Cannon – Manning Capillary tubes of sizes 12 & 13
- Kinematic Viscometer Bath with a provision for 6 tests
- Vacuum System
- Thermometer of IP-5C of a range from 2 to 300°C as per specification
- Thermometer of IP-64C of a range from – 20 to 102°C (0.2° resolution)
Optional Accessories:
EKE 53203: Cannon – Manning Capillary tubes of size of 12
EKE 53204: Cannon – Manning Capillary tubes of size of 13
EKE 53211: Cannon – Fenske Capillary tubes of size of 6
EKE 53212: Cannon – Fenske Capillary tubes of size of 7
EKE 53213: Thermometer of IP-5C of a range from 2 to 300°C as per specification
EKE 53214: Thermometer of IP-64C of a range from – 20 to 102°C (0.2° resolution)
Cannon – Manning /Fenske Viscometer (EKE 532-2)
Cannon – Manning /Fenske Viscometer --
Ref. Standard IS: 1206 (II) & IS IS:1206 (III)
EKE 532-2:
Cannon – Manning Viscometers are designed for the determination of the absolute viscosity of bitumen & Cut – backs by a vacuum capillary method at specified temperatures. Cannons Fenske Viscometers are designed for the determination of the Kinematic viscosity by a vacuum capillary method.
Various types of Glass capillary viscometer are used to measure the viscosities because no single capillary Viscometer is ideally suited for all viscosity determinations.
Suitable for operation on 220 V, 50 Hz, single Phase AC Supply
Features:
• Used for the measurement of absolute viscosity of highly materials
• Viscometers of sizes 12 & 13
• Applicable to materials of viscosities in the range of 360 to 8000 poise
Cannon – Manning Fenske Viscometer Compressing the following:
- Cannon – Manning Capillary tubes of sizes 6 & 7
- Kinematic Viscometer Bath with a provision for 6 tests
- Vacuum System
- Thermometer of IP-5C of a range from 2 to 300°C as per specification
- Thermometer of IP-640 of a range from – 20 to 102°C (0.2° resolution)
Optional Accessories:
EKE 53203: Cannon – Manning Capillary tubes of size of 12
EKE 53204: Cannon – Manning Capillary tubes of size of 13
EKE 53211: Cannon – Fenske Capillary tubes of size of 6
EKE 53212: Cannon – Fenske Capillary tubes of size of 7
EKE 53213: Thermometer of IP-5C of a range from 2 to 300°C as per specification
EKE 53214: Thermometer of IP-640 of a range from – 20 to 102°C (0.2° resolution)
